L600 / 6 Series Driveline Parts  1000 Series

L600 / 6 Series Universal Joints


(A) 0.9687 " x (B) 2.312 "



 Part No  Vendor  Detail
 1-1475  Neapco
 200-600 Weasler
 1-0616 Neapco converts L6 to 1000 series

L600 / 6 Series Rectangular Parts

2
3
4
5
6

Tube Yoke #

1.50" x .065

Tube

Rectangular Sleeve .750"x.875 "

Solid Shaft

.750x.875"

Bar Yoke #

701-0600
602-0600
510-0600
73-0750

300-0600

16-6129
Shield #69-0648
Shield Bearing #56-1600




  Half Shafts

Yoke # 700-0600 or 16-6131

Yoke # 300-0600 or 16-6129

Yoke & Tube Length cuj-end Yoke & Bar Length cuj-end
64-1647
24"
65-1627
24"
64-1639
36"
65-1639
36"
64-1651
48"
65-1651
48"



L600 / 6 Series Splined Parts


2
3
4
5

Spline

Dimensions

Splined Bar Yoke #

Splined shaft

Spline Sleeve

Tube Yoke #

1.00" - 15

301-0600

no shield groove

404-1615
510-0615

702-0600 (1.50x.065)

no shield groove

1.00" - 15

302-0600

1.375 OD groove
404-1615
510-0615

703-0600

1.375 OD groove
Shield #69-0648
Shield Bearing #56-???





L600 / 6 Series Quick Disconnect Yokes
Part Number Diameter Splines Length (cuj-end) Collar or Pin Kit
 101-0610  0.981  10
 105-0615  1.00"  15
 100-0621  1.375  21
 100-0606  1.375  6





L600 / 6 Series Clamp Yokes



Splined

Part Number Diameter Number of Splines Bore Length cuj-end
 807-0615  1.00  15        splined

Round

Part Number Diameter Key Bore Length Length cuj-end
 807-0614  0.875  .187        round
 06091-2664  0.875  0.188        round
 807-0616  1.00  0.250        round





L600 / 6 Series Straight Bores



Round

Part Number Bore Key (cuj-e) Length Bore Length Notes
 806-0610  0.625  .187
 806-0612  0.750  0.187 / 0.250
 806-0613  0.812  0.187 / 0.250
 806-0614  0.875  0.187 / 0.250
 806-0616  1.00  0.187 / 0.250
 806-0618  1.125  0.250 / 0.312
 806-0619  1.187  0.250 / 0.312
 806-0620  1.250  0.250 / 0.312  2.5

Splined

Part Number Diameter Splines (S) Length (Q) Bore (R) Seal ... Notes / Model
 06011-1000  0.875  20
 06011-3255  0.875  13
 06011-3258  0.875  20
 801-0618  1.125  6
 801-0606  1.375  6
Square
Part Number Bore (D) Length Bore Length Notes
 804-0612  0.750  2.50
 804-0614  0.875  2.50
 804-0615  0.9375  2.50
 804-0616  1.00  2.50
 804-0618  1.125  2.50
 804-0620  1.250  2.50
Hex
Part Number Bore (D) Length Bore Length Notes
 16-6303  0.875





L600 / 6 Series Sleeve Yokes

Square

Part Number (C) Bore Bore Type (D) Length
 16-6176  0.75    5.5  808-0612
 808-0612  0.750    5.50
 813-0600  0.750x.875  rect  5.50
 16-6178  0.875    5.5  808-0614
 808-0614  0.875    5.50

Splined

Part Number Diameter Splines (J) Length (F) Length Angle Dust Cap
 812-0615  1.00  15  5.5      none

L600 / 6 Series H Yoke

Part Number Length Angle
 16-8600  2.50"



 L600 / 6 Series Yokeshafts
Part Number Diameter Splines (K) Length (L) Length of Spline (R) Length of Shaft Angle Notes
 16-1615  1.00  15  5.375
 106-0615  1.00  15  5.375
Yokeshaft Calculations
