PTO Universal Joints
Insert a value for conversion // Reference Table ►►
Universal Joint Table
(A) Cup
in.
mm
(B) Length
in.
mm
Series
Part No.
click for pricing
Vendor
0.709
18.0
1.850
47.0
2000
041197W
Walterscheid
0.787
20.0
1.969
50.0
190
41220
Bondioli & Pavesi
0.866
22.0
2.126
54.0
SFT-S1
41201
Bondioli & Pavesi
0.866
22.0
2.126
54.0
SIZE 1
41201
Bondioli & Pavesi
0.866
22.0
2.165
55.0
2100
040116
Walterscheid
0.866
22.0
2.992
76.0
SFT-S2 CV
Bondioli & Pavesi
0.866
22.0
3.386
86.0
SFT-S4 CV
4120E0051
Bondioli & Pavesi
0.937
23.8
2.413
61.3
SIZE 2
41202
Bondioli & Pavesi
0.945
24.0
2.402
61.0
2200
044439
Walterscheid
0.945
24.0
2.402
61.0
2280
367701
Walterscheid
0.969
24.6
1.453
36.9
6 / 0600
200-0600
Weasler
1.000
25.4
3.937
100.0
3DR
200-0300
Weasler
1.062
27.0
1.812
46.0
12 / 1200
200-1200
Weasler
1.063
27.0
2.756
70.0
SIZE 3
41203
Bondioli & Pavesi
1.063
27.0
2.756
70.0
WI
040127
Walterscheid
1.063
27.0
2.933
74.5
2300
044444
Walterscheid
1.063
27.0
2.937
74.6
SIZE 4
41204
Bondioli & Pavesi
1.063
27.0
2.953
75.0
2380
382701
Walterscheid
1.063
27.0
3.937
100.0
SFT-S6 CV
4120G0051R30
Bondioli & Pavesi
1.063
27.0
3.937
100.0
SFT-H7CV
4120G0051
Bondioli and Pavesi
1.125
28.6
2.625
66.7
14 / 2000
200-1400
Weasler
1.189
30.2
3.126
79.4
SFT-S6
4120G0012
Bondioli & Pavesi
1.189
30.2
3.150
80.0
SIZE 5
41205
Bondioli & Pavesi
1.189
30.2
3.413
86.7
BYP 240
41291 * 412910011
Bondioli & Pavesi
1.189
30.2
3.602
91.5
SFT-S7
4120H0012
Bondioli & Pavesi
1.189
30.2
3.622
92.0
SIZE 6
41206R
Bondioli & Pavesi
1.189
30.2
3.913
99.4
SIZE 6 CV
412060023
Bondioli & Pavesi
1.189
30.2
4.173
106.0
SFT-S8 CV
4120L0051R
Bondioli & Pavesi
1.189
30.2
4.803
122.0
SFT-S9 CV
4120M0052
Bondioli & Pavesi
1.250
31.8
3.219
81.8
35N / 2200
200-3501
Weasler
1.251
31.8
3.200
81.3
35N CV
200-3545
Weasler
1.251
31.8
3.219
81.8
35N / 2200
200-3500
Weasler
1.260
32.0
2.992
76.0
2400
312410
Walterscheid
1.260
32.0
2.992
76.0
2480
342221
Walterscheid
1.260
32.0
2.992
76.0
PW480
135077
Walterscheid
1.310
33.3
2.797
71.0
44R
3-0044
Weasler
1.339
34.0
3.543
90.0
WII
040703
Walterscheid
1.374
34.9
3.701
94.0
SFT-S8
4120L0012
Bondioli & Pavesi
1.374
34.9
4.173
106.0
SFT-S9
4120M0012
Bondioli & Pavesi
1.374
34.9
4.409
112.0
SFT-SH CV
4120N0051
Bondioli & Pavesi
1.378
35.0
3.701
94.0
SIZE 7
41207
Bondioli & Pavesi
1.378
35.0
4.173
106.0
CAT6 CV
204-6806
Weasler
1.378
35.0
4.193
106.5
SIZE 8
41208
Bondioli & Pavesi
1.417
36.0
3.504
89.0
2500
312209
Walterscheid
1.417
36.0
3.504
89.0
2580
384316
Walterscheid
1.417
36.0
3.504
89.0
PW580
116497
Walterscheid
1.533
38.9
3.720
94.5
55N CV
200-5556
Weasler
1.533
38.9
4.300
109.2
55N
3-0045
Weasler
1.614
41.0
4.252
108.0
SIZE 9
41209
Bondioli & Pavesi
1.614
41.0
4.646
118.0
SIZE 10
41210
Bondioli & Pavesi
1.654
42.0
4.094
104.0
2600
326245
Walterscheid
1.654
42.0
4.094
104.0
2600 PRO
326245
Walterscheid
1.654
42.0
4.232
107.5
SFT-SH
4120N0012
Bondioli & Pavesi
1.654
42.0
5.118
130.0
SFT-SO
4120S0012
Bondioli & Pavesi
1.781
45.2
4.968
126.2
77
201-7700
WEASLER
1.850
47.0
5.205
132.2
BYP 700
41295
Bondioli & Pavesi
1.929
49.0
5.315
135.0
SIZE 12
412200001
Bondioli & Pavesi
1.969
50.0
4.646
118.0
2700
377635
Walterscheid
2.087
53.0
5.276
134.0
2800
147712
Walterscheid
999.000
10,000.0
999.000
10,000.0
EK
EK CLUTCHES
Walterscheid
