industrial, slip

Order online or call 800-824-0706

Drive Line Service of Fresno, CA

1 - 2 - 3 - Help

1) Select the type of part you are looking for from the left hand menu. Click the link.

2) From the list, click the part number you are interested in to open a new window and see pricing information.

3) If this is the part you need, click < add to shopping cart > in the upper right hand portion of the window.

Note that our catalog is not 100% complete. We are working on that. What we have catalogged are the parts we recognized a demand for. Please call if you cannot find what you need.



Series >

Series link

 Vendor tube size flange OD number of holes ff-weld angle effective slip Model Part No
ELBE 100 6x8 218 80 0.109.071.201
ELBE 100 6x8 244 100 0.110.070.001
ELBE 120 8x8 244 100 0.110.071.001
ELBE 120 8x8 308 120 0.112.070.201
ELBE 120 8x10 320 130 0.113.070.001
ELBE 120 8x10 332 130 0.113.075.001
ELBE 150 8x10 308 120 0.112.071.201
ELBE 150 8x10 320 130 0.113.071.001
ELBE 150 4x13 412 110 0.117.070.701
ELBE 150 12x12 412 110 0.117.070.001
ELBE 150 8x12 328 110 1.148.070.001
ELBE 150 8x12 475 110 0.158.070.001
ELBE 180 10x16 448 110 0.120.070.001
ELBE 180 10x16 496 140 0.122.070.001
ELBE 225 8x16 496 110 0.122.071.001
ELBE 58 4x5 160 40 0.105.070.001
ELBE 65 4x6 160 40 0.105.071.001
ELBE 65mm 4x6 177 60 0.106.070.001
ELBE 75 6x6 177 60 0.106.071.001
ELBE 75 6x6 197 30 70 0.107.070.001
ELBE 90 4x8 197 70 0.107.071.001
ELBE 90 4x8 222 80 0.109.070.201
