1) Select the type of part you are looking for from the left hand menu. Click the link.
2) From the list, click the part number you are interested in to open a new window and see pricing information.
3) If this is the part you need, click < add to shopping cart > in the upper right hand portion of the window.
Note that our catalog is not 100% complete. We are working on that. What we have catalogged are the parts we recognized a demand for. Please call if you cannot find what you need.
 |
|
Series link |
Vendor | flange pattern | holes | compressed | extended | Model | Part No | ||
| ELBE | DIN 100 | 6X8 | 255 | 285 | 0.110.130.001 | ||||
| ELBE | DIN 120 | 8X8 | 325 | 360 | 0.112.130.201 | ||||
| ELBE | DIN 120 | 8X8 | 360 | 410 | 0.112.130.202 | ||||
| ELBE | DIN 120 | 8X8 mm | 255 | 285 | 0.110.131.001 | ||||
| ELBE | DIN 150 | 8X10 | 360 | 400 | 0.148.130.007 | ||||
| ELBE | DIN 150 | 8X10 | 400 | 480 | 0.148.130.008 | ||||
| Elbe | DIN 150 | 8X10 | 460 | 540 | 0.148.140.007 | ||||
| Elbe | DIN 150 | 8X12 | 360 | 400 | YOKESHAFT | 0.148.130.001 | |||
| ELBE | DIN 150 | 8X12 | 400 | 480 | 0.148.130.002 | ||||
| Elbe | DIN 150 | 8X12 | 460 | 540 | 0.148.140.001 | ||||
| Elbe | DIN 180 | 8X12 | 360 | 400 | 0.148.131.001 | ||||
| Elbe | DIN 180 | 8X12 | 400 | 480 | 0.148.131.002 | ||||
| ELBE | DIN 58 | 4X5 | 165 | 185 | 0.105.130.001 | ||||
| ELBE | DIN 58 | 4X5 | 175 | 200 | 0.105.130.002 | ||||
| ELBE | DIN 65 | 4X6 | 180 | 200 | 0.106.130.001 | ||||
| ELBE | DIN 65 | 4X6 | 200 | 230 | 0.106.130.002 | ||||
| ELBE | DIN 75 | 6X6 | 200 | 225 | 0.107.130.001 | ||||
| ELBE | DIN 75 | 6X6 | 225 | 260 | 0.107.130.002 | ||||
| ELBE | DIN 90 | 4X8 | 225 | 250 | 0.109.130.201 | ||||
| ELBE | DIN 90 | 4X8 | 250 | 290 | 0.109.130.202 | ||||
| ELBE | DIN-100 | 6X8mm | 280mm | 320mm | 0.110.130.002 | ||||
| ELBE | DIN-100 | 6X8mm | 218mm | 238mm | 0.110.130.6006 | ||||
| ELBE | DIN-180 | 8x12mm | 495mm | 575mm | 0.158.131.6007 | ||||
| ELBE | DIN-180 | 8x14mm | 430mm | 480mm | 0.158.131.6005 | ||||
| ELBE | DIN-75 | 4x8.5mm | 200mm | 225mm | 0.107.130.021 | ||||
| ELBE | Din58 | 4x5mm | 215 | 240 | 0.105.140.002 | ||||
| GKN | NA | NA | 5.25 | 6.50 | 5C-1 | ||||
| GKN | NA | NA | 5.625 | 6.687 | 5C-1A | ||||
| GKN | NA | NA | 6.937 | 9.625 | 5C-2A | ||||
| GKN | NA | NA | 4.75 | 5.50 | 6C-1A | ||||
| GKN | NA | NA | 6.00 | 7.25 | 6C-2A | ||||
| GKN | NA | NA | 5.62 | 7.00 | 6C-3A | ||||
| GKN | NA | NA | 7.50 | 9.50 | 6C-3A1 | ||||
| GKN | NA | NA | 8.50 | 11.00 | 6C-3A2 | ||||
| GKN | NA | NA | 9.38 | 11.88 | 6C-4A | ||||
| GKN | NA | NA | 11.50 | 16.50 | 6C-5A | ||||
| GKN | NA | NA | 12.25 | 17.25 | 6C-6A | ||||
| GKN | NA | NA | 5.30 | 6.20 | 7C-1A | ||||
| GKN | NA | NA | 5.87 | 7.00 | 7C-1A1 | ||||
| GKN | NA | NA | 6.75 | 8.00 | 7C-2A | ||||
| GKN | NA | NA | 7.20 | 8.87 | 7C-3A | ||||
| GKN | NA | NA | 7.70 | 9.70 | 7C-4A | ||||
| GKN | NA | NA | 9.30 | 13.25 | 7C-5A | ||||
| GKN | NA | NA | 9.50 | 11.50 | 7C-6A | ||||
| GKN | NA | NA | 10.00 | 12.87 | 7C-7A | ||||
| GKN | NA | NA | 11.00 | 13.75 | 7C-8A | ||||
| GKN | NA | NA | 11.25 | 14.50 | 8C-1A | ||||
| GKN | NA | NA | 12.00 | 16.00 | 8.5C - 8C | 8C-2A | |||
| GKN | NA | NA | 8.19 | 9.50 | 8C-3A | ||||
| GKN | NA | NA | 9.50 | 12.25 | 8C-4A | ||||
| GKN | NA | NA | 10.38 | 12.44 | 8C-5A | ||||
| GKN | NA | NA | 12.75 | 15.75 | 8C-5A1 | ||||
| GKN | NA | NA | 13.75 | 16.87 | 8C-6A | ||||
| ELBE | na | na | 5.315 c-c | 6.3 c-c | 0-105-080-101 | ||||
| ELBE | na | na | 6.103 c-c | 7.088 c-c | 0-105-080-102 | ||||
| ELBE | na | na | 4.134 c-c | 5.119 c-c | 0-105-081-101 | ||||
| ELBE | na | na | 6.124 c-c | 7.306 c-c | 0-106-080-101 | ||||
| ELBE | na | na | 6.733 c-c | 7.915 c-c | 0-106-080-102 | ||||
| ELBE | na | na | 4.567 c-c | 5.354 c-c | 0-106-081-101 | ||||
| ELBE | na | na | 7.008 c-c | 8.386 c-c | 0-107-080-101 | ||||
| ELBE | na | na | 7.795 c-c | 9.173 c-c | 0-107-080-102 | ||||
| ELBE | na | na | 5.04 c-c | 6.025 c-c | 0-107-081-101 | ||||
| ELBE | na | na | 6.024 c-c | 7.402 c-c | 0-107-081-102 | ||||
| ELBE | na | na | 7.717 c-c | 9.292 c-c | 0-109-080-201 | ||||
| ELBE | na | na | 8.898 c-c | 10.473 c-c | 0-109-080-202 | ||||
| ELBE | na | na | 4.960 c-c | 5.747 c-c | 0-110-081-022 | ||||
| ELBE | na | na | 5.826 c-c | 6.613 c-c | 0-110-081-016 | ||||
| ELBE | na | na | 6.418 c-c | 7.6 c-c | 0-110-081-101 | ||||
| ELBE | na | na | 7.402 c-c | 8.977 c-c | 0-110-081-102 | ||||
| Elbe | none | none | 230 | 270 | YOKESHAFT | YOKESHAFT | 0.148.081.003 | ||
| Dana Spicer | SAE 1550 | 4 | 10 | 11 | 204249-6 | ||||
| Elbe | SAE 1600 | 8X.375" | 360 | 400 | 0.148.138.001 | ||||
| Dana Spicer | SAE1610 | 8 | 9.125 | 9.875 | 906224-1 | ||||
| Dana Spicer | SAE1710 | 8 | 11.1 | 12.125 | 904657-1 | ||||
| Dana Spicer | SAE1810 | 12 | 13.4 | 14.5 | 906052-1 |
